6 Inch Lift Kit Ford Super Duty 4WD (2017-2022)
Features
Take your truck to new heights with Rough Country's 6in Radius Arm Suspension Lift! This all-inclusive kit comes with everything you need for a total trasnformation of your truck. Run up to 37in tires while preserving the smooth, factory ride quality with this impressive upgrade.
- Easy bolt-on installation
- Increased ground clearance
- Levels the front with the rear of the vehicle
- Radius arm drop brackets allow for properly set caster. Proper caster is crucial to maintaining factory handling and driveability.
- Includes application valved N3 series shock absorbers which offer the best in balanced performance for on and off-road use.
- Fabricated blocks are stronger and offer a longer lifespan than cast blocks.
- Specially designed anti-axle wrap rear blocks maintain stock ride quality while eliminating common lift block problem.
- 10-Stage Variable Valving
- High Pressure Nitrogen Charged
- 35mm Piston
- Chromed Hardened 18mm Piston Rod
- 36kN Tensile Strength
- Spring Loaded Piston Rod Seal
- Metallic Silver Paint
- Silver powder coat finish
- 3-year Manufacturer's Warranty
- Monotube design
- Internal floating piston
- Nitrogen-charged
- 46mm high-flow piston
- Fast heat dissipation
- 36kN Tensile Strength
- Mounts inverted
- T6061 brushed aluminum body
- 3-year Manufacturer's Warranty
- 8-Stage Adjustable Damping
- Monotube Design
- Nitrogen-charged
- Massive 2.5in Piston
- 22mm Chrome-Hardened Piston Rod
- 3-Stage Seal System
- Heat-Treated, Alloy Bearing
- Honed Steel Body
- 3-year Manufacturer's Warranty
Optional Premium N3 Shocks
Optional V2 Monotube Shocks
Optional Vertex Shocks
Fitment Notes
- Models equipped with a 10-speed transmission must remove dial pin.
- Does NOT fit gas engine models.
- Does NOT fit dually models.
- Does NOT fit manual shift transfer cases
- Does NOT work on models equipped with Tremor Factory Trim Package
Installation
GET IT INSTALLED
Don’t want to install it yourself? Search for installers in your area.
FITMENT
Vehicles
Year : 2017 - 2022
Make : Ford
Model : F-350 Super Duty
Drive : 4WD
Year : 2017 - 2022
Make : Ford
Model : F-250 Super Duty
Drive : 4WD
Always read all product page details for more important fitment information
Tires
Size: 35x12.50R20
Wheel: 20x10
Bolt: 8x170
Offset: -18
Note: -
Size: 35x12.50R20
Wheel: 20x10
Bolt: 8x170
Offset: -19
Note: -
Size: 35x12.50R20
Wheel: 20x12
Bolt: 8x170
Offset: -44
Note: Trimming Required
Size: 35x12.50R22
Wheel: 22x10
Bolt: 8x170
Offset: -19
Note: -
Size: 35x12.50R22
Wheel: 22x12
Bolt: 8x170
Offset: -44
Note: Trimming Required
Size: 37x12.50R17
Wheel: 17x9
Bolt: 8x170
Offset: +0
Note: -
Size: 37x12.50R17
Wheel: 17x9
Bolt: 8x170
Offset: +1
Note: -
Size: 37x12.50R17
Wheel: 17x9
Bolt: 8x170
Offset: -12
Note: -
Size: 37x12.50R18
Wheel: 18x9
Bolt: 8x170
Offset: +0
Note: -
Size: 37x12.50R18
Wheel: 18x9
Bolt: 8x170
Offset: +1
Note: -
Size: 37x12.50R18
Wheel: 18x9
Bolt: 8x170
Offset: -12
Note: -
Size: 37x12.50R20
Wheel: 20x10
Bolt: 8x170
Offset: -18
Note: -
Size: 37x12.50R20
Wheel: 20x10
Bolt: 8x170
Offset: -19
Note: -
Size: 37x12.50R20
Wheel: 20x10
Bolt: 8x170
Offset: -24
Note: -
Size: 37x12.50R20
Wheel: 20x10
Bolt: 8x170
Offset: -25
Note: -
Size: 37x12.50R20
Wheel: 20x12
Bolt: 8x170
Offset: -44
Note: Trimming Required
Size: 37x12.50R20
Wheel: 20x9
Bolt: 8x170
Offset: +0
Note: -
Size: 37x12.50R20
Wheel: 20x9
Bolt: 8x170
Offset: +1
Note: -
Size: 37x12.50R20
Wheel: 20x9
Bolt: 8x170
Offset: -12
Note: -
Size: 37x12.50R22
Wheel: 22x10
Bolt: 8x170
Offset: -19
Note: -
Size: 37x12.50R22
Wheel: 22x10
Bolt: 8x170
Offset: -24
Note: -
Size: 37x12.50R22
Wheel: 22x10
Bolt: 8x170
Offset: -25
Note: -
Size: 37x12.50R22
Wheel: 22x9
Bolt: 8x170
Offset: +0
Note: -
Size: 37x12.50R22
Wheel: 22x9
Bolt: 8x170
Offset: +1
Note: -
Size: 37x12.50R22
Wheel: 22x9
Bolt: 8x170
Offset: -12
Note: -
Due to differences in manufacturing, dimension and inflated measurements, tire & wheel combinations should be test fit prior to installation
About this Product
6 Inch Lift Kit | Ford Super Duty 4WD (2017-2022)
