6 Inch Lift Kit Jeep Wrangler TJ 4WD (1997-2006)

STARTING PRICE
$1,349.95
STARTING PRICE
$1,349.95
Configure Your Kit:
Shipping Soon
Order will ship once stocking is complete.

SKU:

66220


Brand:

Rough Country


Lowest Price Guarantee
Select Matching Wheels and Tires
Select Matching Wheels and Tires
FREE Mount, Balance, and Shipping!

Features

Venture far beyond the limits of a stock Wrangler with Rough Country's all-inclusive 6-inch X-Series Lift for Jeep TJ. Level the front of your vehicle with the rear while gaining enough increased ground clearance to run up to 35-inch tires.
  • Easy bolt-on installation
  • Increased ground clearance
  • Levels the front with the rear of the vehicle
  • Front adjustable track bar is made of forged solid steel for unsurpassed strength and durability
  • Coil springs are progressive rate for enhanced ride quality.
  • Quick disconnects quickly and easily store out of the way when not in use.
  • Includes application valved N3 series shock absorbers which offer the best in balanced performance for on and off-road use.
  • X-Flex control arm features:
    • durable OEM style rubber bushings.
    • Flex joints feature a massive 2.5" diameter body and 1.25" thread.
    • Fully greasable.
    • Upper joints pivot up to 20 degrees.
    • Lower joints pivot up to 35 degrees.
Fitment Notes
  • Transfer case drop kit or Slip Yoke Eliminator with CV Drive Shaft is recommended to avoid driveline vibration. View CV Drive Shafts here.
  • Rubicon models do not need a SYE kit or transfer case drop but a CV driveshaft is still recommended.
Warranty Details

Est. Install Time 6-8 hours

Shock Configuration Options

N3 Shock Pair
Premium N3
included
  • 10-Stage Variable Valving

  • High Pressure Nitrogen Charged

  • 35mm Piston

  • Chromed Hardened 18mm Piston Rod

  • 54mm Shock Body to dissipate heat faster

  • 36kN Tensile Strength

  • Spring Loaded Piston Rod Seal

  • Military Spec. Fluid Rated To –40° C

  • Rubber bushings for better absorption

  • Metallic Silver Paint

  • 3-year Manufacturer's Warranty

Customer Support Headshot
Need Help?
Talk to a Build Expert
1-800-222-7023

Installation


GET IT INSTALLED

Don’t want to install it yourself? Search for installers in your area.


FITMENT

Vehicles

Year : 2004 - 2006

Make : Jeep

Model : Wrangler Unlimited

Drive : 4WD

Year : 1997 - 2006

Make : Jeep

Model : Wrangler

Drive : 4WD

Year : 2005 - 2006

Make : Jeep

Model : Wrangler Unlimited Rubicon

Drive : 4WD

Year : 2003 - 2006

Make : Jeep

Model : Wrangler Rubicon

Drive : 4WD

Always read all product page details for more important fitment information

Tires

Size: 35x12.50R15

Wheel: 15x10

Bolt Pattern: 5x4.5

Wheel Offset: -39

Note: Trimming Required

Stance: -

Size: 35x12.50R15

Wheel: 15x8

Bolt Pattern: 5x4.5

Wheel Offset: -18

Note: -

Stance: -

Size: 35x12.50R15

Wheel: 15x8

Bolt Pattern: 5x4.5

Wheel Offset: -19

Note: -

Stance: -

Size: 35x12.50R16

Wheel: 16x10

Bolt Pattern: 5x4.5

Wheel Offset: -39

Note: Trimming Required

Stance: -

Size: 35x12.50R16

Wheel: 16x8

Bolt Pattern: 5x4.5

Wheel Offset: -12

Note: -

Stance: -

Size: 35x12.50R16

Wheel: 16x8

Bolt Pattern: 5x4.5

Wheel Offset: -6

Note: -

Stance: -

Size: 285/75R17

Wheel: 17x8.5

Bolt Pattern: 5x4.5

Wheel Offset: -12

Note: -

Stance: -

Size: 305/70R17

Wheel: 17x8.5

Bolt Pattern: 5x4.5

Wheel Offset: +0

Note: -

Stance: -

Size: 305/70R17

Wheel: 17x8.5

Bolt Pattern: 5x4.5

Wheel Offset: +1

Note: -

Stance: -

Size: 305/70R17

Wheel: 17x8.5

Bolt Pattern: 5x4.5

Wheel Offset: -12

Note: -

Stance: -

Size: 35x12.50R17

Wheel: 17x8.5

Bolt Pattern: 5x4.5

Wheel Offset: +0

Note: -

Stance: -

Size: 35x12.50R17

Wheel: 17x8.5

Bolt Pattern: 5x4.5

Wheel Offset: +1

Note: -

Stance: -

Size: 285/75R17

Wheel: 17x9

Bolt Pattern: 5x4.5

Wheel Offset: +0

Note: -

Stance: -

Size: 285/75R17

Wheel: 17x9

Bolt Pattern: 5x4.5

Wheel Offset: +1

Note: -

Stance: -

Size: 305/70R17

Wheel: 17x9

Bolt Pattern: 5x4.5

Wheel Offset: +0

Note: -

Stance: -

Size: 305/70R17

Wheel: 17x9

Bolt Pattern: 5x4.5

Wheel Offset: +1

Note: -

Stance: -

Size: 305/70R17

Wheel: 17x9

Bolt Pattern: 5x4.5

Wheel Offset: -12

Note: -

Stance: -

Size: 315/70R17

Wheel: 17x9

Bolt Pattern: 5x4.5

Wheel Offset: +0

Note: -

Stance: -

Size: 315/70R17

Wheel: 17x9

Bolt Pattern: 5x4.5

Wheel Offset: +1

Note: -

Stance: -

Size: 35x12.50R17

Wheel: 17x9

Bolt Pattern: 5x4.5

Wheel Offset: +0

Note: -

Stance: -

Size: 35x12.50R17

Wheel: 17x9

Bolt Pattern: 5x4.5

Wheel Offset: +1

Note: -

Stance: -

Size: 35x12.50R17

Wheel: 17x9

Bolt Pattern: 5x4.5

Wheel Offset: -12

Note: -

Stance: -

Size: 295/70R18

Wheel: 18x10

Bolt Pattern: 5x4.5

Wheel Offset: -18

Note: -

Stance: -

Size: 295/70R18

Wheel: 18x10

Bolt Pattern: 5x4.5

Wheel Offset: -19

Note: -

Stance: -

Size: 285/75R18

Wheel: 18x8.5

Bolt Pattern: 5x4.5

Wheel Offset: +0

Note: -

Stance: -

Size: 285/75R18

Wheel: 18x8.5

Bolt Pattern: 5x4.5

Wheel Offset: +1

Note: -

Stance: -

Size: 295/70R18

Wheel: 18x8.5

Bolt Pattern: 5x4.5

Wheel Offset: +0

Note: -

Stance: -

Size: 295/70R18

Wheel: 18x8.5

Bolt Pattern: 5x4.5

Wheel Offset: +1

Note: -

Stance: -

Size: 35x12.50R18

Wheel: 18x8.5

Bolt Pattern: 5x4.5

Wheel Offset: +0

Note: -

Stance: -

Size: 35x12.50R18

Wheel: 18x8.5

Bolt Pattern: 5x4.5

Wheel Offset: +1

Note: -

Stance: -

Size: 295/70R18

Wheel: 18x9

Bolt Pattern: 5x4.5

Wheel Offset: +0

Note: -

Stance: -

Size: 295/70R18

Wheel: 18x9

Bolt Pattern: 5x4.5

Wheel Offset: +1

Note: -

Stance: -

Size: 295/70R18

Wheel: 18x9

Bolt Pattern: 5x4.5

Wheel Offset: -12

Note: -

Stance: -

Size: 35x12.50R18

Wheel: 18x9

Bolt Pattern: 5x4.5

Wheel Offset: +0

Note: -

Stance: -

Size: 35x12.50R18

Wheel: 18x9

Bolt Pattern: 5x4.5

Wheel Offset: +1

Note: -

Stance: -

Size: 35x12.50R18

Wheel: 18x9

Bolt Pattern: 5x4.5

Wheel Offset: -12

Note: -

Stance: -

Size: 295/60R20

Wheel: 20x10

Bolt Pattern: 5x4.5

Wheel Offset: -18

Note: Minor Trimming

Stance: -

Size: 295/60R20

Wheel: 20x10

Bolt Pattern: 5x4.5

Wheel Offset: -19

Note: Minor Trimming

Stance: -

Size: 35x12.50R20

Wheel: 20x10

Bolt Pattern: 5x4.5

Wheel Offset: -18

Note: Minor Trimming

Stance: -

Size: 35x12.50R20

Wheel: 20x10

Bolt Pattern: 5x4.5

Wheel Offset: -19

Note: Minor Trimming

Stance: -

Size: 295/60R20

Wheel: 20x9

Bolt Pattern: 5x4.5

Wheel Offset: -12

Note: -

Stance: -

Size: 35x12.50R20

Wheel: 20x9

Bolt Pattern: 5x4.5

Wheel Offset: -12

Note: -

Stance: -

Due to differences in manufacturing, dimension and inflated measurements, tire & wheel combinations should be test fit prior to installation

Select Matching Wheels and Tires
Select Matching Wheels and Tires
FREE Mount, Balance, and Shipping!
About this Product

6 Inch Lift Kit | Jeep Wrangler TJ 4WD (1997-2006)
