2.5 Inch Lift Kit 4-Door | Jeep Wrangler Unlimited Rubicon 4WD (2024-2025)
STARTING PRICE
$549.95
STARTING PRICE
$549.95
Features
- Hassle-Free Installation: Features a 100% bolt-on design with no cutting or welding required for a smooth, DIY-friendly setup.
- Front-to-Rear Leveling: Eliminates factory rake by bringing the front end in line with the rear for a clean, leveled stance.
- Enhanced Ground Clearance: Gain extra ride height to better tackle obstacles and uneven terrain with confidence.
- Factory-Tuned Coil Springs: Engineered to match OEM spring rates, maintaining factory ride quality while supporting the lift.
- Tire Clearance up to 35 Inches: Run larger tires for an aggressive look and improved off-road capability.
- Custom Shock Options: Select from nitrogen-charged N3 shocks, V2, M1 Monotube, or premium M1R shocks for a ride tailored to your off-road needs and preferences.
Fitment Notes
- Fits 4-door models ONLY.
- Due to variances in coil spring rate this kit ONLY fits Rubicon models.
- Due to variances in coil spring rate this kit NOT fit 4xe models.
- Due to variances in coil spring rate this kit NOT fit 392 models.
- 35" tires will clear, but rubbing may occur with extreme articulation.
- If planning on running 35" tires on factory wheels, double-check clearance between the front tire, lower control arm, and sway-bar links.
Shock Configuration Options
Premium N3
included10-Stage Variable Valving
High Pressure Nitrogen Charged
35mm Piston
Chromed Hardened 18mm Piston Rod
54mm Shock Body to dissipate heat faster
36kN Tensile Strength
Spring Loaded Piston Rod Seal
Military Spec. Fluid Rated To –40° C
Rubber bushings for better absorption
Metallic Silver Paint
3-year Manufacturer's Warranty
M1 Monotube
+$140.002-inch seamless extruded tube.
46mm digressive piston.
Self-adjusting, deflective-disc independent rebound and compression.
18mm centerless-ground, case-hardened, chromed, and super-polished rod.
46mm monotube design ensures consistent, fade-free performance in all conditions.
Digressive valving instantly reacts to changing surface conditions.
Zinc plated for resistance against harsh elements.
Available in various lift heights for multiple applications.
Durable vulcanized natural rubber bushings.
3-year Manufacturer's Warranty
V2 Monotube
+$320.00Incredible ride quality & performance
Monotube design
Internal floating piston
Nitrogen-charged
46mm high-flow piston
Fast heat dissipation
36kN Tensile Strength
Mounts inverted
T6061 brushed aluminum body
3-year Manufacturer's Warranty
Installation
GET IT INSTALLED
Don’t want to install it yourself? Search for installers in your area.
FITMENT
Vehicles
year: 2026
make: Jeep
model: Wrangler Rubicon X
drive: 4WD
year: 2026
make: Jeep
model: Wrangler Rubicon
drive: 4WD
year: 2024 - 2025
make: Jeep
model: Wrangler Willys
drive: 4WD
year: 2024 - 2025
make: Jeep
model: Wrangler
drive: 4WD
year: 2024 - 2025
make: Jeep
model: Wrangler
drive: 4WD
year: 2024
make: Jeep
model: Wrangler Willys Sport
drive: 4WD
Always read all product page details for more important fitment information
Wheels & Tires
size: 35x12.50R17
Popular
wheel: 17x9
Bolt Pattern: 5x5.0
Wheel Offset: +0
note: -
Stance: 1
size: 35x12.50R18
Popular
wheel: 18x9
Bolt Pattern: 5x5.0
Wheel Offset: +0
note: -
Stance: 1
size: 35x12.50R20
Popular
wheel: 20x9
Bolt Pattern: 5x5.0
Wheel Offset: +0
note: -
Stance: 1
size: 35x12.50R22
Popular
wheel: 22x10
Bolt Pattern: 5x5.0
Wheel Offset: -12
note: Minor Trimming
Stance: 2
size: 35x12.50R17
wheel: Factory 17
Bolt Pattern: 5x5.0
Wheel Offset: -
note: 1.5 Spacer
Stance: 0
size: 35x12.50R18
wheel: Factory 18
Bolt Pattern: 5x5.0
Wheel Offset: -
note: 1.5 Spacer
Stance: 0
size: 35x12.50R17
wheel: 17x8.5
Bolt Pattern: 5x5.0
Wheel Offset: +0
note: -
Stance: 1
size: 35x12.50R17
wheel: 17x8.5
Bolt Pattern: 5x5.0
Wheel Offset: +1
note: -
Stance: 1
size: 315/70R17
wheel: 17x9
Bolt Pattern: 5x5.0
Wheel Offset: +0
note: -
Stance: 1
size: 315/70R17
wheel: 17x9
Bolt Pattern: 5x5.0
Wheel Offset: +1
note: -
Stance: 1
size: 35x12.50R17
wheel: 17x9
Bolt Pattern: 5x5.0
Wheel Offset: +1
note: -
Stance: 1
size: 35x12.50R17
wheel: 17x9
Bolt Pattern: 5x5.0
Wheel Offset: -12
note: -
Stance: 1
size: 275/75R18
wheel: 18x8.5
Bolt Pattern: 5x5.0
Wheel Offset: +0
note: -
Stance: 1
size: 275/75R18
wheel: 18x8.5
Bolt Pattern: 5x5.0
Wheel Offset: +1
note: -
Stance: 1
size: 285/75R18
wheel: 18x8.5
Bolt Pattern: 5x5.0
Wheel Offset: +0
note: -
Stance: 1
size: 285/75R18
wheel: 18x8.5
Bolt Pattern: 5x5.0
Wheel Offset: +1
note: -
Stance: 1
size: 295/70R18
wheel: 18x8.5
Bolt Pattern: 5x5.0
Wheel Offset: +0
note: -
Stance: 1
size: 295/70R18
wheel: 18x8.5
Bolt Pattern: 5x5.0
Wheel Offset: +1
note: -
Stance: 1
size: 35x12.50R18
wheel: 18x8.5
Bolt Pattern: 5x5.0
Wheel Offset: +0
note: -
Stance: 1
size: 35x12.50R18
wheel: 18x8.5
Bolt Pattern: 5x5.0
Wheel Offset: +1
note: -
Stance: 1
size: 275/75R18
wheel: 18x9
Bolt Pattern: 5x5.0
Wheel Offset: -12
note: -
Stance: 1
size: 285/75R18
wheel: 18x9
Bolt Pattern: 5x5.0
Wheel Offset: -12
note: -
Stance: 1
size: 295/70R18
wheel: 18x9
Bolt Pattern: 5x5.0
Wheel Offset: +0
note: -
Stance: 1
size: 295/70R18
wheel: 18x9
Bolt Pattern: 5x5.0
Wheel Offset: +1
note: -
Stance: 1
size: 295/70R18
wheel: 18x9
Bolt Pattern: 5x5.0
Wheel Offset: -12
note: -
Stance: 1
size: 35x12.50R18
wheel: 18x9
Bolt Pattern: 5x5.0
Wheel Offset: +1
note: -
Stance: 1
size: 35x12.50R18
wheel: 18x9
Bolt Pattern: 5x5.0
Wheel Offset: -12
note: -
Stance: 1
size: 275/65R20
wheel: 20x10
Bolt Pattern: 5x5.0
Wheel Offset: -25
note: -
Stance: 2
size: 295/60R20
wheel: 20x10
Bolt Pattern: 5x5.0
Wheel Offset: -18
note: -
Stance: 2
size: 295/60R20
wheel: 20x10
Bolt Pattern: 5x5.0
Wheel Offset: -19
note: -
Stance: 2
size: 295/60R20
wheel: 20x10
Bolt Pattern: 5x5.0
Wheel Offset: -24
note: -
Stance: 2
size: 295/60R20
wheel: 20x10
Bolt Pattern: 5x5.0
Wheel Offset: -25
note: -
Stance: 2
size: 295/65R20
wheel: 20x10
Bolt Pattern: 5x5.0
Wheel Offset: -25
note: -
Stance: 2
size: 35x11.50R20
wheel: 20x10
Bolt Pattern: 5x5.0
Wheel Offset: -25
note: -
Stance: 2
size: 35x12.50R20
wheel: 20x10
Bolt Pattern: 5x5.0
Wheel Offset: -18
note: -
Stance: 2
size: 35x12.50R20
wheel: 20x10
Bolt Pattern: 5x5.0
Wheel Offset: -19
note: -
Stance: 2
size: 35x12.50R20
wheel: 20x10
Bolt Pattern: 5x5.0
Wheel Offset: -25
note: -
Stance: 2
size: 35x12.50R20
wheel: 20x12
Bolt Pattern: 5x5.0
Wheel Offset: -44
note: Trimming required
Stance: 2
size: 295/60R20
wheel: 20x9
Bolt Pattern: 5x5.0
Wheel Offset: +0
note: -
Stance: 1
size: 295/60R20
wheel: 20x9
Bolt Pattern: 5x5.0
Wheel Offset: +1
note: -
Stance: 1
size: 295/60R20
wheel: 20x9
Bolt Pattern: 5x5.0
Wheel Offset: -12
note: -
Stance: 1
size: 35x12.50R20
wheel: 20x9
Bolt Pattern: 5x5.0
Wheel Offset: +1
note: -
Stance: 1
size: 35x12.50R20
wheel: 20x9
Bolt Pattern: 5x5.0
Wheel Offset: -12
note: -
Stance: 1
size: 35x12.50R22
wheel: 22x10
Bolt Pattern: 5x5.0
Wheel Offset: -18
note: Minor Trimming
Stance: 2
size: 35x12.50R22
wheel: 22x10
Bolt Pattern: 5x5.0
Wheel Offset: -19
note: Minor Trimming
Stance: 2
size: 35x12.50R22
wheel: 22x10
Bolt Pattern: 5x5.0
Wheel Offset: -24
note: Minor Trimming
Stance: 2
size: 35x12.50R22
wheel: 22x10
Bolt Pattern: 5x5.0
Wheel Offset: -25
note: Minor Trimming
Stance: 2
size: 35x12.50R22
wheel: 22x12
Bolt Pattern: 5x5.0
Wheel Offset: -44
note: Trimming required
Stance: 2
Due to differences in manufacturing, dimension and inflated measurements, tire & wheel combinations should be test fit prior to installation
