2.5 Inch Lift Kit Ram 2500 4WD (2014-2018)
Features
Lift, level, and smooth out your ride with Rough Country's new and improved 2.5-inch RAM 2500 Leveling Kit. Engineered to fit RAM trucks equipped with front radius arm suspension setups, this easy-to-install kit gives a big boost at an unbelievable price!
- Easy bolt-on installation.
- Maintains factory ride quality.
Fitment Notes
- Does NOT fit rear air-ride models.
- Does NOT fit Power Wagon models.
Shock Configuration Options
Premium N3
included10-Stage Variable Valving
High Pressure Nitrogen Charged
35mm Piston
Chromed Hardened 18mm Piston Rod
54mm Shock Body to dissipate heat faster
36kN Tensile Strength
Spring Loaded Piston Rod Seal
Military Spec. Fluid Rated To –40° C
Rubber bushings for better absorption
Metallic Silver Paint
3-year Manufacturer's Warranty
M1 Monotube
+$120.002-inch seamless extruded tube.
46mm digressive piston.
Self-adjusting, deflective-disc independent rebound and compression.
18mm centerless-ground, case-hardened, chromed, and super-polished rod.
46mm monotube design ensures consistent, fade-free performance in all conditions.
Digressive valving instantly reacts to changing surface conditions.
Zinc plated for resistance against harsh elements.
Available in various lift heights for multiple applications.
Durable vulcanized natural rubber bushings.
3-year Manufacturer's Warranty
V2 Monotube
+$320.00Incredible ride quality & performance
Monotube design
Internal floating piston
Nitrogen-charged
46mm high-flow piston
Fast heat dissipation
36kN Tensile Strength
Mounts inverted
T6061 brushed aluminum body
3-year Manufacturer's Warranty
Installation
GET IT INSTALLED
Don’t want to install it yourself? Search for installers in your area.
FITMENT
Vehicles
Year : 2014 - 2018
Make : Ram
Model : 2500
Drive : 4WD
Always read all product page details for more important fitment information
Tires
Size: 285/45R22
Wheel: 22x10
Bolt: 8x6.5/8x165.1
Offset: -19
Note: -
Size: 285/55R20
Wheel: 20x10
Bolt: 8x6.5/8x165.1
Offset: -18
Note: -
Size: 285/55R20
Wheel: 20x10
Bolt: 8x6.5/8x165.1
Offset: -19
Note: -
Size: 285/55R20
Wheel: 20x9
Bolt: 8x6.5/8x165.1
Offset: +0
Note: -
Size: 285/55R20
Wheel: 20x9
Bolt: 8x6.5/8x165.1
Offset: +1
Note: -
Size: 295/55R20
Wheel: 20x9
Bolt: 8x6.5/8x165.1
Offset: +0
Note: -
Size: 295/55R20
Wheel: 20x9
Bolt: 8x6.5/8x165.1
Offset: +12
Note: -
Size: 295/55R20
Wheel: 20x9
Bolt: 8x6.5/8x165.1
Offset: -12
Note: -
Size: 295/70R18
Wheel: 18x8.5
Bolt: 8x6.5/8x165.1
Offset: +0
Note: -
Size: 295/70R18
Wheel: 18x9
Bolt: 8x6.5/8x165.1
Offset: +0
Note: -
Size: 295/70R18
Wheel: 18x9
Bolt: 8x6.5/8x165.1
Offset: +12
Note: -
Size: 295/70R18
Wheel: 18x9
Bolt: 8x6.5/8x165.1
Offset: -12
Note: -
Size: 305/55R20
Wheel: 20x10
Bolt: 8x6.5/8x165.1
Offset: -18
Note: -
Size: 305/55R20
Wheel: 20x10
Bolt: 8x6.5/8x165.1
Offset: -19
Note: -
Size: 305/55R20
Wheel: 20x9
Bolt: 8x6.5/8x165.1
Offset: +0
Note: -
Size: 305/55R20
Wheel: 20x9
Bolt: 8x6.5/8x165.1
Offset: +1
Note: -
Size: 305/70R17
Wheel: 17x8.5
Bolt: 8x6.5/8x165.1
Offset: +0
Note: -
Size: 305/70R17
Wheel: 17x9
Bolt: 8x6.5/8x165.1
Offset: +0
Note: -
Size: 305/70R17
Wheel: 17x9
Bolt: 8x6.5/8x165.1
Offset: +12
Note: -
Size: 305/70R17
Wheel: 17x9
Bolt: 8x6.5/8x165.1
Offset: -12
Note: -
Due to differences in manufacturing, dimension and inflated measurements, tire & wheel combinations should be test fit prior to installation
About this Product
2.5 Inch Lift Kit | Ram 2500 4WD (2014-2018)
