4.5 Inch Lift Kit Toyota Tundra 2WD/4WD (2007-2015)
Features
- Unmatched ground clearance due to high clearance crossmember design.
- 100% precision laser cut materials used in latest computer aided design process.
- Levels the front with the rear of the vehicle
- Will work with factory 18-inch or larger wheels.
- No strut disassembly or strut compressor required for installation.
- Fabricated blocks are stronger and offer a longer lifespan than cast blocks.
- Requires no modification to the stock differential mounts, drivetrain or exhaust.
- Incredible ride quality & performance
- Monotube design
- Nitrogen-charged
- 46mm high-flow piston
- Mounts inverted
- 36kN Tensile Strength
- 3-year Manufacturer's Warranty
- Maintains smooth, factory-like ride
- Infinitely Variable Damping
- Leak-proof piston seal
- Massive 1 3/8in Bore
- Increased ground clearance
- Only fits 4WD models
- 3-year Limited Warranty
Optional V2 Monotube Shocks
Optional N3 Struts
Fitment Notes
- N3 Loaded Struts are ONLY for 4WD models.
- Does NOT fit Pro Series models
- Does NOT fit Rock Warrior models
- Does NOT fit XSP-X models.
- Minor cutting and drilling is required.
- Requires 18-inch or larger wheels.
- Stock 18-inch or larger wheels can be used but can accommodate tires no wider than 11.5-inch.
- In some cases minor trimming may be needed to clear 35-inch tires.
- On vehicles equipped with a two piece driveshaft there is the potential for take off vibration, this can be corrected with SKU: 1776BOX1 carrier bearing shim kit.
Installation
GET IT INSTALLED
Don’t want to install it yourself? Search for installers in your area.
FITMENT
Vehicles
Year : 2007 - 2015
Make : Toyota
Model : Tundra
Drive : 4WD
Year : 2007 - 2015
Make : Toyota
Model : Tundra
Drive : RWD
Always read all product page details for more important fitment information
Tires
Size: 35x12.50R18
Wheel: 18x8.5
Bolt Pattern: 5x150
Wheel Offset: +0
Note: Minor Trimming
Stance: -
Size: 35x12.50R18
Wheel: 18x8.5
Bolt Pattern: 5x150
Wheel Offset: +1
Note: Minor Trimming
Stance: -
Size: 35x12.50R18
Wheel: 18x9
Bolt Pattern: 5x150
Wheel Offset: +0
Note: Minor Trimming
Stance: -
Size: 35x12.50R18
Wheel: 18x9
Bolt Pattern: 5x150
Wheel Offset: +1
Note: Minor Trimming
Stance: -
Size: 35x12.50R18
Wheel: 18x9
Bolt Pattern: 5x150
Wheel Offset: +18
Note: -
Stance: -
Size: 35x12.50R18
Wheel: 18x9
Bolt Pattern: 5x150
Wheel Offset: +20
Note: -
Stance: -
Size: 35x12.50R18
Wheel: 18x9
Bolt Pattern: 5x150
Wheel Offset: -12
Note: Minor Trimming
Stance: -
Size: 295/60R20
Wheel: 20x10
Bolt Pattern: 5x150
Wheel Offset: -18
Note: Trimming Required
Stance: -
Size: 295/60R20
Wheel: 20x10
Bolt Pattern: 5x150
Wheel Offset: -19
Note: Trimming Required
Stance: -
Size: 295/60R20
Wheel: 20x9
Bolt Pattern: 5x150
Wheel Offset: +18
Note: -
Stance: -
Size: 295/60R20
Wheel: 20x9
Bolt Pattern: 5x150
Wheel Offset: +20
Note: -
Stance: -
Size: 35x12.50R20
Wheel: 20x9
Bolt Pattern: 5x150
Wheel Offset: +0
Note: Minor Trimming
Stance: -
Size: 35x12.50R20
Wheel: 20x9
Bolt Pattern: 5x150
Wheel Offset: +1
Note: Minor Trimming
Stance: -
Size: 35x12.50R20
Wheel: 20x9
Bolt Pattern: 5x150
Wheel Offset: +18
Note: -
Stance: -
Size: 35x12.50R20
Wheel: 20x9
Bolt Pattern: 5x150
Wheel Offset: +20
Note: -
Stance: -
Size: 35x12.50R20
Wheel: 20x9
Bolt Pattern: 5x150
Wheel Offset: -12
Note: Minor Trimming
Stance: -
Size: 295/50R22
Wheel: 22x10
Bolt Pattern: 5x150
Wheel Offset: -18
Note: Trimming Required
Stance: -
Size: 295/50R22
Wheel: 22x10
Bolt Pattern: 5x150
Wheel Offset: -19
Note: Trimming Required
Stance: -
Due to differences in manufacturing, dimension and inflated measurements, tire & wheel combinations should be test fit prior to installation
About this Product
4.5 Inch Lift Kit | Toyota Tundra 2WD/4WD (2007-2015)
