5 Inch Lift Kit FR Spacer | Radius Arm Drop | Ram 2500 4WD (14-18)
SKU:
35720
Brand:
Rough Country
Features
- Increased ground clearance
- Maintains factory progressive rate coil springs
- Track bar bracket keeps the front axle properly centered.
- Fits both rear coil spring and rear air ride suspension models!
- Rear ride height arm brackets let you adjust the rear ride height, up to 1-inch higher than the front - Air Ride models ONLY
- Includes application valved N3 series shock absorbers which offer the best in balanced performance for on and off-road use.
Fitment Notes
- Does NOT fit "Power Wagon" models.
- Requires drilling and cutting.
- On vehicles equipped with a two piece driveshaft & carrier bearing as on the Mega Cab, there is the potential for take off vibration, depending on the severity, this can be corrected with shimming down the carrier bearing. SKU: 1161.
Installation
GET IT INSTALLED
Don’t want to install it yourself? Search for installers in your area.
FITMENT
Vehicles
Year : 2014 - 2018
Make : Ram
Model : 2500
Drive : 4WD
Always read all product page details for more important fitment information
Tires
Size: 37x12.50R17
Wheel: 17x9
Bolt: 8x6.5/8x165.1
Offset: +0
Note: -
Size: 37x12.50R18
Wheel: 18x9
Bolt: 8x6.5/8x165.1
Offset: +0
Note: -
Size: 37x12.50R20
Wheel: 20x10
Bolt: 8x6.5/8x165.1
Offset: -18
Note: Trimming Required
Size: 37x12.50R20
Wheel: 20x10
Bolt: 8x6.5/8x165.1
Offset: -19
Note: Trimming Required
Size: 37x12.50R20
Wheel: 20x9
Bolt: 8x6.5/8x165.1
Offset: +0
Note: -
Size: 37x12.50R20
Wheel: 20x9
Bolt: 8x6.5/8x165.1
Offset: +1
Note: Minor Trimming
Size: 37x12.50R22
Wheel: 22x10
Bolt: 8x6.5/8x165.1
Offset: -19
Note: Minor Trimming
Due to differences in manufacturing, dimension and inflated measurements, tire & wheel combinations should be test fit prior to installation
About this Product
5 Inch Lift Kit | FR Spacer | Radius Arm Drop | Ram 2500 4WD (14-18)
