3.25 Inch Lift Kit Combo | Chevy/GMC Canyon/Colorado (15-22)
SKU:
924
Brand:
Rough Country
Features
- Maintains factory ride quality
- Increased ground clearance
- Works with factory wheels
- Levels the front of the vehicle with the rear
- Body lift includes front and rear bumper brackets
- Body lift pucks are made from fiberglass reinforced nylon for superior strength and durability
- Body lift features 10.9 grade body mount bolts
- Body lift hardware is zinc coated to protect against the elements
Fitment Notes
- Does NOTfit models with Duramax diesel engine
- Does NOT fit Trail Boss/ZR2 models.
- Requires drilling
- If offset wheels are used, trimming may be required
- If installing aftermarket wheels or wheel spacers, it is highly recommended they be hub-centric
- Rear bumper brackets are to enhance appearance only, bumper cannot be used for towing
- If equipped with factory fender flares - Front flares must be removed to install the front bumper brackets. To reinstall, new double sided tape is required.
Installation
GET IT INSTALLED
Don’t want to install it yourself? Search for installers in your area.
FITMENT
Vehicles
Year : 2015 - 2022
Make : Chevy
Model : Colorado
Drive : 4WD
Year : 2015 - 2022
Make : Chevy
Model : Colorado
Drive : RWD
Year : 2015 - 2022
Make : GMC
Model : Canyon
Drive : RWD
Year : 2015 - 2022
Make : GMC
Model : Canyon
Drive : 4WD
Always read all product page details for more important fitment information
Tires
Size: 265/65R18
Wheel: 18x9
Bolt: 6x5.5
Offset: +0
Note: Trimming Required
Size: 265/65R18
Wheel: 18x9
Bolt: 6x5.5
Offset: +1
Note: Trimming Required
Size: 265/70R17
Wheel: Factory 17
Bolt: 6x120
Offset: -
Note: -
Size: 285/55R20
Wheel: 20x9
Bolt: 6x5.5
Offset: +0
Note: Trimming Required
Size: 285/55R20
Wheel: 20x9
Bolt: 6x5.5
Offset: +1
Note: Trimming Required
Size: 285/65R18
Wheel: 18x9
Bolt: 6x5.5
Offset: +0
Note: Trimming Required
Size: 285/65R18
Wheel: 18x9
Bolt: 6x5.5
Offset: +1
Note: Trimming Required
Size: 285/70R17
Wheel: 17x9
Bolt: 6x5.5
Offset: +0
Note: Trimming Required
Size: 285/70R17
Wheel: 17x9
Bolt: 6x5.5
Offset: +1
Note: Trimming Required
Size: 305/55R20
Wheel: 20x9
Bolt: 6x5.5
Offset: +0
Note: Trimming Required
Size: 305/55R20
Wheel: 20x9
Bolt: 6x5.5
Offset: +1
Note: Trimming Required
Size: 32x11.50R16
Wheel: 16x8
Bolt: 6x5.5
Offset: +30
Note: -
Size: 33x12.50R17
Wheel: 17x9
Bolt: 6x5.5
Offset: +0
Note: Trimming Required
Size: 33x12.50R17
Wheel: 17x9
Bolt: 6x5.5
Offset: +1
Note: Trimming Required
Size: 33x12.50R20
Wheel: 20x9
Bolt: 6x5.5
Offset: +0
Note: Trimming Required
Size: 33x12.50R20
Wheel: 20x9
Bolt: 6x5.5
Offset: +1
Note: Trimming Required
Due to differences in manufacturing, dimension and inflated measurements, tire & wheel combinations should be test fit prior to installation
About this Product
3.25 Inch Lift Kit | Combo | Chevy/GMC Canyon/Colorado (15-22)
